High speed model single facer SF30 with more flute types

New Technical on Single Facer SF30

On the single facer SF30, we can see lots of new technical and advantage. For example, the gaps of empty flute and gluing flute, it can be adjusted automatically, and about the gluing volume, it can be tracked by the running speed and paper quality automatically. The pressure between the flute roller and pressure roller is also can be adjusted automatically. Also its intelligence functions reflect on all difference systems.

What we should consider before purchasing a single facer

After years working of the old corrugated cardboard production line, some factory do not want to by a new production line, to be instead of this, they prefer to buy some new machine which works in the production line to be instead of old machine. To be the heart of the whole production line, if we want to choose a new single facer to work in old production line, we have to consider things as below:

1. What is our old production line design speed, the new single facer should be corresponding to the old line, if the single facer speed is lower than the old line, then the production line can only run in lower speed, if the new single facer speed is higher than old line, then it will be waste money on paying new single facer, because it can not run in its design speed.
2. We have to check the working width of the old production line, the new single facer working with have to be equal or bigger than the old production line, or the whole production line can only work for smaller width.
3. The operation side of the old production line, some of machine in the production line, it does not need to classify the operation side, but for single facer, it has to be classified the operation side. How to classify the operation side of single facer, normally we called the production line is left operation and right operation, when we stand at the stacker of the production line, face to the mill roll stand direction, if the operation tables are on our left side, then the production line is right operation, if the operation is on our right side, then the production line is left operation. So when we buy a new single facer, we have to tell the carton machine manufacture the operation side.
4. The flute type is a essential data for purchasing a new single facer, it has lots of types, we have to tell the carton machine manufacture the teeth quantity in 300mm, the teeth height, then the manufacture can make sure the flute type.
5. For high speed, high intelligence corrugated paperboard production line, if we want a new single facer for it, we have to consider the old production line with a production manage system, if there is a LAN on the production line control, so we need to check if the single facer can connect with the manage system.
6. Heating method is also an important data for a new single facer, the new single facer heating method have to be as same as the old corrugated paperboard production line, or it can not work in the production line.

All in all, the new single facer has to be matched with the old corrugated cardboard production line.
