parameters：
| Width | 2800mm |
| Design speed | 300m/min |
| layer | 1-2-3 |
| Tension correction control | Electric deviation correction suction tension |
| Power source | 380V 50Hz 13KW |
| Size | |
| Weight |
main parts parameter：
| Name | Specification | Material | Surface treatment |
| Feeding roller and tension roller | ￠155mm | 45＃ | Circular grinding, chrome plating and polishing |
| Conveyer roller | ￠210mm | 45＃ | Circular grinding, chrome plating and polishing |
| Pass and guide roller | ￠128mm | 45＃ | Circular grinding, chrome plating and polishing |
| Loading carriage shaft | ￠155mm | 45＃ | Circular grinding, chrome plating and polishing |
main drive parameters：
| Name | Power | Voltage | Hz |
| Single face paper lift motor | 7.5KW | 380V | 50HZ |
| Paper width adjust motor | 250W | 380V | 50HZ |
main parts brand and origin：
| No. | Name | Brand and origin | Remarks |
| 01 | Frame | Tianjin or Jinan steel | 25# channel、15# H、12# channel、63# angle、60*80 square steel。 |
| 02 | Rail | Tianjin steel | ￠42mm low press liquid pipe |
| 03 | Lifting belt | Shanghai | PVC delivery belt |
| 04 | Cardboard conveyer belt | Hebei | Parallel transport rubber belt |
| 06 | Frequency converter | Delta | |
| 07 | Bearing | NSK | |
| 08 | Bearing with seat | Fujian | |
| 09 | Width adjust reducer | Shandong | |
| 10 | Feeding motor（frequency conversion） | Hengshui | 7.5KW |
| 11 | Conveyer pass and guiding roller | Seamless steel pipe | Surface chrome plating |
| 12 | Electrics | SIEMENS | Contactor, relay,button |
| 13 | Timing belt | Ningbo | 8m |
